SUS304 hot saled 2016carbonated drink filling machine/carbonated
water filler
Introduction
Drink Filling Machine combines washing, filling and rotary capping
functions in one unit, it is a fully automatic and high efficiency
liquid packing equipment. It is suitable for packing beverage
containing gas. Its performance is as follwing: all parts, for
instance, filling valve, which directly contact medium are made of
stainless steel or harmless material. So it conforms to the
requirements of Food sanitation. Sealing parts are made of
heat-proofing rubber, in order to meet the technique requirements
of users to sterilization at high temperature.
Characteristics
1. Using the wind sent access and move wheel in the bottle directly
connected technology; canceled screw and conveyor chains, this
enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology,
bottle-shaped transform not need to adjust the equipment level,
only change related the curved plate, wheel and nylon parts is
enough..
3. The specially designed stainless steel bottle washing machine
clip is solid and durable, no touch with the screw location of
bottle mouth to avoid secondary pollution.
4.. Host adopts advanced PLC automatic control technology, the key
electrical component from famous company such as Japan's
Mitsubishi, France Schneider, OMRON.
Technical parameters
| Item | DCGF16-12-6 | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-10 |
| Capacity | 4000bph(500ml) | 5000bph(500ml) | 8000bph(500ml) | 15000bph(500ml) |
| Rising heads | 16 | 18 | 24 | 32 |
| Filling heads | 12 | 18 | 24 | 2 |
| Capping heads | 6 | 6 | 8 | 10 |
| Bottle Diameter | Commonly 50-110mm (can adjustable) |
| Bottle Height | Commonly 150-340mm(can adjustable) |
| Filling pressure | 0.15-0.35Mpa |
| Rising pressure | 0.2-0.25Mpa |
| Overall size | 2130*1700*2350 | 2450*1800*2350 | 2780*2200*2350 | 3600*2650*2350 |
| Weight | 3.3t | 3.5t | 4.5t | 5.5t |
Services
1.Installation
After equipments reached the workshop of customer, place the
equipments according to plane layout we offered. We will arrange
seasoned technician for equipments installation, debug and test
production at the same time make the equipments reach the rated
producing capacity of the line. Time for installation and debug is
15-25 days.
2.Training
Our company offer technology training to customer. The content of
training is structure and maintenance of equipments, control and
operation of equipments. Training is in the workshop of customer.
Seasoned technician will guide and establish training outline.
After training, the technician of buyer could master the operation
and maintenance, could adjust the process and treat different
failures.
3.Quality Guarantee
We promise that our goods are all new and not used. They’re made of
suitable material, adopt new design. The quality, specification and
function all meet the demand of contract. We promise that the
products of this line could storage for one year without adding any
aseptic.
