Mango Juice Bottling Production Line Hot Filling Machine Small Automatic 6.68 Kw

    Buy cheap Mango Juice Bottling Production Line Hot Filling Machine Small Automatic 6.68 Kw from wholesalers

    Buy cheap Mango Juice Bottling Production Line Hot Filling Machine Small Automatic 6.68 Kw from wholesalers
    • Buy cheap Mango Juice Bottling Production Line Hot Filling Machine Small Automatic 6.68 Kw from wholesalers

    Mango Juice Bottling Production Line Hot Filling Machine Small Automatic 6.68 Kw

    Ask Lasest Price
    Brand Name : jiayuan
    Model Number : RCGF18-18-6
    Certification : CE,ISO,SGS
    Price : US $15,000 - 800,000 / Set |
    Supply Ability : 10 Set/Sets per Month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Mango Juice Bottling Production Line Hot Filling Machine Small Automatic 6.68 Kw

    Complete Hot Filling Machine Small Automatic Fruit Apple Orange Mango Juice Bottling Production Line


    1) Feature

    This filling machine is mainly designed for filling hot temperature liquid into glass bottle; For example juice, tea drinks etc which are made of concentrate juice. The final filling temperature will be around 85-90 degree centigrade; Once the thermal meter in juice filling machine is lower than the temperature, juice will be return to sterilizing machine again through return system. Glass bottle juice filling machine is different from plastic bottle. It will be optional and suggested to apply 4 in 1 filling machine, one more washing system is adopted to warm up the glass bottle in advance.


    2) Technique parameter

    RCGF18-18-6RCGF24-24-8
    Productivity6000BPH10000BPH
    Rinsing Head1824
    Filling Head1824
    Capping Head68
    Bottle Volume350ml~2000ml±10ml
    Bottle Diameterφ50-92mm
    Bottle Height150-310 mm
    Filling Tolerance±2%
    Cap Size28mm and 30mm PE Standard Caps
    Air Pressure0.6MPa
    Air Consumption500 L/min
    Filling Water Consumption3 m3/h6 m3/h
    Rinsing Water Consumption1 m3/h2 m3/h
    Motor Power6.68kW7.68kW
    Voltage380V
    Dimension(L×W×H) 2450*1800*2200mm(L×W×H) 2750*2180*2200mm
    Weight3000kg5300kg
    Filling PrincipleGravity Filling
    Our advantage

    Why choice us?

    Design AbilityAll the machines designed by CAD
    Manufacturing AbilityMechanical parts: high quality stainless steel, processed by CNC
    ReliabilityElectrical parts from world famous suppliers
    Professional

    Focus on beverage and cosmetics packing machines

    Exported to over 20 countries with good reputation

    6 years Alibaba Golden supplier without complaint

    Good ServiceService include complete production line design, manufacturing, on-site installation & aftersales maintenance.
    Profession on ExportAuthorized export licence.
    Export Market

    Our machine has been sold to more than 40 countries,almost of the customers are satisfiedwith the machines and our service.
