Specification
1.washing,pulp filling, capping 4-in-1 monobloc
2.Material: Stainless steel
3.Juice filling machine, hot filling production line, fruit pulp
juice making machine, juice bottling machine, fruit juice pacing
machine, hot tea filling plant
3.Zhangjiagang, Suzhou, Jiangsu province
Feature:
1. The module of screw capper ensures the tightness of the cap and
avoids bottle damage
2. Slight negative-pressure gravity circumfluence filling system
increases juice filling accuracy and reduces contamination
3. Unique control mechanism keeps circumfluence volume below 5%
4. Airtight valve made of non-plastic material prevents worn-out
particles from dropping into bottles adversely affecting product
quality
5. High efficient clean air filter circulation system ensures high
sanitary requirements
6. Low overall machines noise that is comparable to any
internationally known equipments in its class
7. Self-lubricationg system imported from America provides
continuous smooth operation
Parameter
| Model | RCGF16-12-6 | RCGF18-18-6 | RCGF24-24-8 |
| Production capacity(500ml)(b/h) | 3000 | 6000 | 10000 |
| Filling precision | ≤±5MM(Liquid Level) | ≤±5MM(Liquid Level) | ≤±5MM(Liquid Level) |
| Feedback consumption | ≤10% | ≤10% | ≤10% |
| Polyester bottle standard(mm) | (BottleDiameter)50-92;(Height):150-310 | (BottleDiameter)50-92;(Height):150-310 | (BottleDiameter)50-92;(Height):150-310 |
| Suitable cap shape | (Plastic Screw Cap) | (Plastic Screw Cap) | (Plastic Screw Cap) |
| Water pressure of washing bottle(Mpa) | 0.18 | 0.18 | 0.18 |
| Wash pressure of washing bottle(kg/h) | 800 | 1600 | 2500 |
| Gas sourse pressure(Mpa) | 0.6 | 0.6 | 0.6 |
| Gas consumption(m3/min | / | 0.3 | 0.4 |
| Total power | 5.88 | 6.68 | 7.68 |
| Total weight | 2500 | 3000 | 4000 |
| Dimensions(L*W*H)(mm) | 2100×1500×2200 | 2450×1800×2200 | 2750×2180×2200 |
Washing part of bottle washing filling capping machine
a) Rotary pan is made of stainless steel 304.
b) The rubber clamp splice seizes the mouth of bottles, which is
fixedness and reliable.
Filling part of bottle washing filling capping machine
a) Rotary pan is made of stainless steel 304
b) The way of filling is gravitation filling.
c) The filling valve is adopted best stainless steel 304
d) The structure of filling valve is reasonable, the amount is
correct
e) When filling the bottle, the bottle is move but the valve is
stationary. The splint of bottle-neck seizes mouth of bottles. The
elevator device with the action of gear realize the up and down of
bottle
Capping part of bottle washing filling capping machine
a) The dropping cap guide track fixes the device which can protect
the cap from turning over and also set the device which can take
out the inverse cap, equip a photo electricity switch which can
stop the machine when lacking the cap and also avoid the situation
that there is bottle without cap.
b) The bottle inlet switch which is set in the capping machine,
with the locking cap which is the connection of the dripping cap
guide track and dialing cap pan controls the discharging of cap,
making sure that stop conveyor cap when there is no bottles ,avoid
the waste of cap.
Our Service
1) One year warranty for the whole system.
2) Free equipment installation and debugging.
3) After one year, we can help you to maintain the machine and the
accessories are provided only one the cost price.
4) We can provide internship service and help you train the
operator and mechanic.
5) Free beverage production technology and process configuration.
6) We can help you to design the product line, workshop and provide
turn-key project.
