    Automatic Pet Bottle Capping And Edible Oil Filling Machine 1900x1800x2200mm

    Ask Lasest Price
    Brand Name : JIAYUAN
    Model Number : YGF18-6
    Certification : CE,ISO,SGS
    Price : US $120,000-1,000,000
    Supply Ability : 15 Set/Sets per Month
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    Automatic Pet Bottle Capping And Edible Oil Filling Machine 1900x1800x2200mm

    Cooking oil bottle filling and capping machine 1900x1800x2200mm






    If you want to know how this machine works,please click here:https://youtu.be/yGhNXFRf_oM


    Specifications

    This machine dopts the principle of plunger quantitative filling, into the bottle, positioning, filling, the

    bottles are automatically controlled by the PLC, in accordance with the GMP standard. Suitable for

    medical, food, daily chemical, pesticide and fine chemical liquid filling.

    Pet bottle oil filling and capping 2 in 1 monoblock, piston volumetric filling,rotary type

    Keywords

    1. Cooking oil bottle filling and capping machine

    2. cooking oil filling machine,oil filling machine

    3. 2-in-1 monoblock

    4. oil bottle filling machine


    Introduction

    1. Automatic cooking oil filling machine is suitable for filling paste or oil product, such as ketchup, jam, fruit

    and vegetable paste, cooking oil, honey, corn soup, peanut paste, sauce. It also can be used for pulp,

    edible bird's nest, aloe, rice wine and so on.

    2. Automatic cooking oil filling machine works stably, fills precisely, and suits for cold and hot filling. The

    piston and piston barrel after the treatment of top technology cooperate accurately, durable and

    wearable. It is equipped with material stirring system, three point liquid level control, frequency conversion

    adjustment, bottle in and out protection, automatic speed adjustment, filling with bottle and no filling

    without bottles. It adopts good stainless steel material, which meet the requirement of food sanitation.

    Vacuum pump can make sure there is no dripping oil on bottle body or machine surface, keep the bottle

    and machine clean.


    Main technical parameter

    Cooking oil bottle filling and capping machine 1900x1800x2200mm

    ModelYGF18-6
    Capacity/1L BOTTLE3000BPH
    Filling head18
    Capping head6
    Filling time5 second(approx)(100ml/min)
    Filling temperature18-20℃
    Filling tankSemi closed type filling tank, using worm gear to adjust the height
    Filling valveUsing cam to force down
    Speed controlAC MOTOR+REDUCER+INVERTER
    Gas consumption100NL/min(5-6Kg/cm²)(take 100EA as the base)
    Power2.2Kw
    Weight2000 Kg

    Overall dimensions
    (LxWxH)mm

    1900x1800x2200






















    Filling heads



    Cap loader



    Air conveyor
